BKQ-B II Vertical Autoclave
Widely used in laboratories, quality control and testing departments, the food industry, and other settings for the sterilization of equipment and medical waste. To ensure an effective sterilization process, the system employs gravity displacement to remove cold air from the sterilization chamber.
Technical Specifications
Model: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II / BKQ-B150(II) / BKQ-B200(II)
Capacity: BKQ-B50II — 50 L; BKQ-B75II — 75 L; BKQ-B100II — 100 L; BKQ-B120II — 120 L; BKQ-B150(II) — 150 L; BKQ-B200(II) — 200 L
Design Pressure: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — 0.28 MPa; BKQ-B150(II) / BKQ-B200(II) — 0.3 MPa
Operating Pressure: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — 0.23 MPa; BKQ-B150(II) / BKQ-B200(II) — 0.217 MPa
Design Temperature: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — 150℃; BKQ-B150(II) / BKQ-B200(II) — 137°C
Operating temperature: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — 105–136°C; BKQ-B150(II) / BKQ-B200(II) — 50–134°C
Temperature accuracy: 0.1°C
Chamber material: S30408
Chamber dimensions: BKQ-B50II — φ386*514 mm; BKQ-B75II — φ386*695 mm; BKQ-B100II — φ386*875 mm; BKQ-B120II — φ386*1055 mm; BKQ-B150(II) — φ500*760 mm; BKQ-B200(II) — φ500*1000 mm
Basket/Mesh-bottom basket/Bucket: BKQ-B50II — φ365*360 mm, 1 pc.; BKQ-B75II — φ365*265 mm, 2 pcs.; BKQ-B100II — φ365*360 mm, 2 pcs.; BKQ-B120II — φ365*360 mm, 1 pc. and φ365*265 mm, 2 pcs.; BKQ-B150(II) — φ470*230 mm, 3 pcs.; BKQ-B200(II) — φ470*230 mm, 4 pcs. Noise: ≤65 dB
Altitude: ≤2700 m
Standard accessory: Basket
Optional accessories: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — printer, mesh-bottom basket, bucket; BKQ-B150(II) / BKQ-B200(II) — printer
Power consumption: BKQ-B50II — 4.4 kW; BKQ-B75II — 4.7 kW; BKQ-B100II — 5.2 kW; BKQ-B120II — 5.2 kW; BKQ-B150(II) / BKQ-B200(II) — 6 kW
Power supply: BKQ-B50II / BKQ-B75II / BKQ-B100II / BKQ-B120II — AC220V, 50/60Hz (standard); AC110V, 50/60Hz (optional); Connection method: Air circuit breaker; BKQ-B150(II) / BKQ-B200(II) — AC380V, 50/60Hz (standard); AC220V, 50/60Hz (optional); Connection method: Air circuit breaker
External dimensions (W*D*H): BKQ-B50II — 640*550*980 mm; BKQ-B75II — 640*550*1080 mm; BKQ-B100II — 640*550*1280 mm; BKQ-B120II — 640*550*1380 mm; BKQ-B150(II) — 630*700*1400 mm; BKQ-B200(II) — 630*700*1600 mm
Net weight: BKQ-B50II — 87 kg; BKQ-B75II — 95 kg; BKQ-B100II — 105 kg; BKQ-B120II — 122 kg; BKQ-B150(II) — 162 kg; BKQ-B200(II) — 180 kg
Packaging dimensions (W*D*H): BKQ-B50II — 750*745*1100 mm; BKQ-B75II — 750*745*1240 mm; BKQ-B100II — 750*745*1450 mm; BKQ-B120II — 750*745*1540 mm; BKQ-B150(II) — 760*800*1530 mm; BKQ-B200(II) — 760*800*1720 mm
Gross weight: BKQ-B50II — 104 kg; BKQ-B75II — 114 kg; BKQ-B100II — 127 kg; BKQ-B120II — 142 kg; BKQ-B150(II) — 213 kg; BKQ-B200(II) — 238 kg
